Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:ENDi
an
Sets or queries the data field endian setting, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-266
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:HEXa
<y>
Sets a data field reference value, which is one of the ID and data conditions,
for FlexRay bus signal triggering in hexadecimal notation.
5-266
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:MODE
Sets or queries the data field enable/disable condition, which is one of the ID
and data conditions, for FlexRay bus signal triggering.
5-266
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:MSBL
sb
Sets or queries the MSB and LSB bits for the data field, which is one of the
ID and data conditions, for FlexRay bus signal triggering.
5-266
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:PATTe
rn<y>
Sets or queries the data field data, which is one of the ID and data
conditions, for FlexRay bus signal triggering in binary notation.
5-266
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:PFORm
at
Sets or queries the data field data input format, which is one of the ID and
data conditions, for FlexRay bus signal triggering.
5-267
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:SIGN
Sets or queries whether a signed or unsigned data format will be used for the
data field (this is one of the ID and data conditions) for FlexRay bus signal
triggering.
5-267
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:FID?
Queries all frame ID settings for the ID and data conditions for FlexRay bus
signal triggering.
5-267
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:FID:CONDition
Sets or queries the frame ID data condition, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-267
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:FID:ID<x>
Sets or queries the Frame ID value, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-267
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:FID:MODE
Sets or queries the Frame ID enable/disable condition, which is one of the ID
and data conditions, for FlexRay bus signal triggering.
5-267
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:INDIcator?
Queries all indicator settings for the ID and data conditions for FlexRay bus
signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:INDIcator:MO
DE
Sets or queries the indicator enable/disable condition, which is one of the ID
and data conditions, for FlexRay bus signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:INDIcator:NFR
ame
Sets or queries the indicator null frame, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:INDIcator:PPR
eamble
Sets or queries the indicator payload preamble, which is one of the ID and
data conditions, for FlexRay bus signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:INDIcator:STF
Rame
Sets or queries the indicator start frame, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:INDIcator:SYF
Rame
Sets or queries the indicator sync frame, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR?
Queries all OR condition settings for FlexRay bus signal triggering. 5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>?
Queries all the settings of the frame IDs, which are OR conditions, for
FlexRay bus signal triggering.
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:CCOunt?
Queries the cycle-count setting for the frame IDs for FlexRay bus signal
triggering (this is one of the OR conditions).
5-268
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:CCOunt:COND
ition
Sets or queries the comparison condition for the cycle counts of the frame
IDs for FlexRay bus signal triggering (this is one of the OR conditions).
5-269
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:CCOunt:COUN
t<y>
Sets or queries the reference value for the cycle counts of the frame IDs for
FlexRay bus signal triggering (this is one of the OR conditions).
5-269
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:FID?
Queries all the ID conditions of the frame IDs for FlexRay bus signal
triggering (this is one of the OR conditions).
5-269
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:FID:CONDiti
on
Sets or queries the ID comparison condition of the frame IDs for FlexRay bus
signal triggering (this is one of the OR conditions).
5-269
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDOR:ID<x>:FID:ID<y>
Sets or queries the ID reference value for the frame IDs for FlexRay bus
signal triggering (this is one of the OR conditions).
5-269
