YOKOGAWA DLM4038 User Manual

5-46
IM DLM4038-17EN
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:ID<x>:MO
DE
Sets or queries the ID enable/disable condition, which is one of the ID OR
conditions, for CAN FD bus signal triggering.
5-262
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:ID<x>:PA
TTern
Sets or queries the ID condition, which is one of the ID OR conditions, for
CAN FD bus signal triggering in binary notation.
5-262
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:MFORmat
Sets or queries the ID frame format (standard or extended), which is one of
the ID OR conditions, for CAN FD bus signal triggering.
5-262
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:MODE
Sets or queries the ID enable/disable condition, which is one of the ID OR
conditions, for CAN FD bus signal triggering.
5-262
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:PFORmat
Sets or queries the ID input format, which is one of the ID OR conditions, for
CAN FD bus signal triggering.
5-262
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:MSIGnal<x>:MESSage:
ITEM
Sets the message item, which is one of the ID OR conditions, for CAN FD
bus signal triggering.
5-262
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:RTR
Sets or queries the RTR, which is one of the ID OR conditions, for CAN FD
bus signal triggering.
5-263
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:MODE
Sets or queries the CAN FD bus signal trigger mode. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:RECessive
Sets or queries the CAN FD bus signal trigger recessive level. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:SOURce
Sets or queries the CAN FD bus signal trigger signal. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:SPOint
Sets or queries the CAN FD bus signal trigger sample point. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray?
Queries all FlexRay bus signal trigger settings. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:BCHannel
Sets or queries the channel bus type for FlexRay bus signal triggering. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:BRATe
Sets or queries the FlexRay bus signal trigger bit rate (data transfer rate). 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:ERRor?
Queries all FlexRay bus signal trigger error settings. 5-263
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:ERRor:BSS
Sets or queries the FlexRay bus signal trigger BSS error setting. 5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:ERRor:CRC
Sets or queries the FlexRay bus signal trigger CRC error setting. 5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:ERRor:FES
Sets or queries the FlexRay bus signal trigger FES error setting. 5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray:IDData?
Queries all ID and data condition settings for FlexRay bus signal triggering. 5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:CCOunt?
Queries all cycle-count settings for the ID and data conditions for FlexRay
bus signal triggering.
5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:CCOunt:CONDit
ion
Sets or queries the cycle-count data condition, which is one of the ID and
data conditions, for FlexRay bus signal triggering.
5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:CCOunt:COUNt
<x>
Sets or queries the cycle count, which is one of the ID and data conditions,
for FlexRay bus signal triggering.
5-264
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:CCOunt:MODE
Sets or queries the cycle-count enable/disable condition, which is one of the
ID and data conditions, for FlexRay bus signal triggering.
5-265
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>?
Queries all data field settings for the ID and data conditions for FlexRay bus
signal triggering.
5-265
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:BCOu
nt
Sets or queries the position for comparing data field data patterns, which is
one of the ID and data conditions, for FlexRay bus signal triggering.
5-265
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:CONDi
tion
Sets or queries the data field data condition, which is one of the ID and data
conditions, for FlexRay bus signal triggering.
5-265
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:DBYTe
Sets or queries the number of data field data bytes, which is one of the ID
and data conditions, for FlexRay bus signal triggering.
5-265
:TRIGger{[:ATRigger]|:BTRigger}
:FLEXray[:IDData]:DATA<x>:DECim
al<y>
Sets a reference value, which is one of the ID and data conditions, for
FlexRay bus signal triggering in hexadecimal notation.
5-265
5.1 List of Commands
