YOKOGAWA DLM4038 User Manual

5-45
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:PATTern<x>
Sets or queries the data value, which is one of the ID and data conditions, for
CAN FD bus signal triggering in binary notation.
5-258
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:PFORmat
Sets or queries the data input format, which is one of the ID and data
conditions, for CAN FD bus signal triggering.
5-258
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:SIGN
Sets or queries whether signed or unsigned data format will be used, which
is one of the ID and data conditions, for CAN FD bus signal triggering.
5-258
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier?
Queries all identifier settings for the ID and data conditions for CAN FD bus
signal triggering.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier:ID?
Queries all identifier settings for the ID and data conditions for CAN FD bus
signal triggering.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier:ID:H
EXa
Sets the ID value, which is one of the ID and data conditions, for CAN FD
bus signal triggering in hexadecimal notation.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier:ID:M
ODE
Sets or queries the ID enable/disable condition, which is one of the ID and
data conditions, for CAN FD bus signal triggering.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier:ID:P
ATTern
Sets or queries the ID condition, which is one of the ID and data conditions,
for CAN FD bus signal triggering in binary notation.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier:MFOR
mat
Sets or queries the ID frame format (standard or extended), which is one of
the ID and data conditions, for CAN FD bus signal triggering.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:IDENtifier:PFOR
mat
Sets or queries the ID input format, which is one of the ID and data
conditions, for CAN FD bus signal triggering.
5-259
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal?
Queries all message and signal settings for the ID and data conditions for
CAN FD bus signal triggering.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal:MESSage
:ITEM
Sets the message item, which is one of the ID and data conditions, for CAN
FD bus signal triggering.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal:SELect
Sets or queries the message and signal condition, which is one of the ID and
data conditions, for CAN FD bus signal triggering.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal:SIGNal?
Queries all signal settings for the ID and data conditions for CAN FD bus
signal triggering.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal:SIGNal:
CONDition
Sets or queries the signal condition, which is one of the ID and data
conditions, for CAN FD bus signal triggering.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal:SIGNal:
DECimal<x>
Sets a signal’s reference value, which is one of the ID and data conditions,
for CAN FD bus signal triggering in decimal notation.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:MSIGnal:SIGNal:
ITEM
Sets the signal item, which is one of the ID and data conditions, for CAN FD
bus signal triggering.
5-260
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:RTR
Sets or queries the RTR, which is one of the ID and data conditions, for CAN
FD bus signal triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR?
Queries all ID OR condition settings for CAN FD bus signal triggering. 5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:ACK?
Queries all ACK settings for the ID OR conditions for CAN FD bus signal
triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:ACK:MODE
Sets or queries the ACK mode, which is one of the ID OR conditions, for
CAN FD bus signal triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:ACK:TYPE
Sets or queries the ACK condition, which is one of the ID OR conditions, for
CAN FD bus signal triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:DATA?
Queries all data settings for the ID OR conditions for CAN FD bus signal
triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:DATA[:MODE]
Sets or queries the data enable/disable condition, which is one of the ID OR
conditions, for CAN FD bus signal triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier?
Queries all identifier settings for the ID OR conditions for CAN FD bus signal
triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:ID<x>?
Queries all ID settings for the ID OR conditions for CAN FD bus signal
triggering.
5-261
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDOR:IDENtifier:ID<x>:HE
Xa
Sets the ID value, which is one of the ID OR conditions, for CAN FD bus
signal triggering in hexadecimal notation.
5-262
5.1 List of Commands
