5-44
IM DLM4038-17EN
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:MODE
Sets or queries the CAN bus signal trigger mode setting. 5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:RECessive
Sets or queries the CAN bus signal trigger recessive level. 5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:SOURce
Sets or queries the CAN bus signal trigger source signal. 5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:SPOint
Sets or queries the CAN bus signal trigger sample point. 5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD?
Queries all CAN FD bus signal trigger settings. 5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:BRATe
Sets or queries the CAN FD bus signal trigger bit rate (data transfer rate). 5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:DBRate
Sets or queries the CAN FD bus signal trigger data phase bit rate (data
transfer rate).
5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:DSPoint
Sets or queries the CAN FD bus signal trigger data phase sample point. 5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame?
Queries all CAN FD bus signal trigger error settings. 5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame:CRC
Sets or queries the CAN FD bus signal trigger CRC error setting. 5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame:CRCEFactor?
Queries all CRC error factor settings for CAN FD bus signal triggering. 5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame:CRCEFactor:CRCSeq
uence
Sets or queries the CRC sequence (a CRC error factor) for CAN FD bus
signal triggering.
5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame:CRCEFactor:SCOunt
Sets or queries the StuffCount (a CRC error factor) for CAN FD bus signal
triggering.
5-255
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame:FSTuff
Sets or queries the CAN FD bus signal trigger fixed stuff error setting. 5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame[:MODE]
Sets or queries the CAN FD bus signal trigger error frame setting. 5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:EFRame:STUFF
Sets or queries the CAN FD bus signal trigger stuff error setting. 5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:FDF:CONDition
Sets or queries the CAN FD bus signal trigger FDF. 5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:FDSTandard
Sets or queries whether the CAN FD bus signal for triggering is an ISO
standard signal.
5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD:IDData?
Queries all ID and data condition settings for CAN FD bus signal triggering. 5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:ACK?
Queries all ACK settings for the ID and data conditions for CAN FD bus
signal triggering.
5-256
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:ACK:MODE
Sets or queries the ACK mode, which is one of the ID and data conditions,
for CAN FD bus signal triggering.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:ACK:TYPE
Sets or queries the ACK condition, which is one of the ID and data
conditions, for CAN FD bus signal triggering.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA?
Queries all data settings for the ID and data conditions for CAN FD bus
signal triggering.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:BCOunt
Sets or queries the pattern comparison position, which is one of the ID and
data conditions, for CAN FD bus signal triggering.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:CONDition
Sets or queries the comparison condition, which is one of the ID and data
conditions, for CAN FD bus signal triggering.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:DBYTe
Sets or queries the number of data bytes, which is one of the ID and data
conditions, for CAN FD bus signal triggering.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:DECimal<x>
Sets a reference values (a, b), which is one of the ID and data conditions, for
CAN FD bus signal triggering in decimal notation.
5-257
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:ENDian
Sets or queries the byte order of the reference values, which is one of the ID
and data conditions, for CAN FD bus signal triggering.
5-258
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:HEXa<x>
Sets a reference value, which is one of the ID and data conditions, for CAN
FD bus signal triggering in hexadecimal notation.
5-258
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:MODE
Sets or queries the data enable/disable condition, which is one of the ID and
data conditions, for CAN FD bus signal triggering.
5-258
:TRIGger{[:ATRigger]|:BTRigger}
:CANFD[:IDData]:DATA:MSBLsb
Sets or queries the MSB and LSB bits for the data, which is one of the ID
and data conditions, for CAN FD bus signal triggering.
5-258
5.1 List of Commands
