YOKOGAWA DLM4038 - Page 76

5-43
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier:ID:PAT
Tern
Sets or queries the ID pattern, which is one of the ID and data conditions, for
CAN bus signal triggering in binary notation.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier:MFORm
at
Sets or queries the ID frame format (standard or extended), which is one of
the ID and data conditions, for CAN bus signal triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier:PFORm
at
Sets or queries the ID input format, which is one of the ID and data
conditions, for CAN bus signal triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal?
Queries all message and signal settings for the ID and data conditions for
CAN bus signal triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal:MESSage:I
TEM
Sets the message item, which is one of the ID and data conditions, for CAN
bus signal triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal:SELect
Sets or queries the message and signal conditions for CAN bus signal
triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal:SIGNal?
Queries all signal settings for the ID and data conditions for CAN bus signal
triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal:SIGNal:CO
NDition
Sets or queries the signal data condition, which is one of the ID and data
conditions, for CAN bus signal triggering.
5-251
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal:SIGNal:DE
Cimal<x>
Sets a signal reference value, which is one of the ID and data conditions, for
CAN bus signal triggering in decimal notation.
5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:MSIGnal:SIGNal:IT
EM
Sets the signal item, which is one of the ID and data conditions, for CAN bus
signal triggering.
5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:RTR
Sets or queries the RTR value, which is one of the ID and data conditions,
for CAN bus signal triggering.
5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR?
Queries all ID OR condition settings for CAN bus signal triggering. 5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:ACK?
Queries all ID OR condition ACK settings for CAN bus signal triggering. 5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:ACK:MODE
Sets or queries the ACK mode, which is one of the ID OR conditions, for
CAN bus signal triggering.
5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:ACK:TYPE
Sets or queries the ACK condition, which is one of the ID OR conditions, for
CAN bus signal triggering.
5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:DATA?
Queries all data settings for the ID OR condition for CAN bus signal
triggering.
5-252
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:DATA[:MODE]
Sets or queries the data enable/disable condition, which is one of the ID OR
conditions, for CAN bus signal triggering.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier?
Queries all identifier settings for the ID OR condition for CAN bus signal
triggering.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:ID<x>?
Queries all ID OR condition ID settings for CAN bus signal triggering. 5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:ID<x>:HEXa
Sets the ID value, which is one of the ID OR conditions, for CAN bus signal
triggering in hexadecimal notation.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:ID<x>:MODE
Sets or queries the ID enable/disable condition, which is one of the ID OR
conditions, for CAN bus signal triggering.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:ID<x>:PATT
ern
Sets or queries the ID pattern, which is one of the ID OR conditions, for CAN
bus signal triggering in binary notation.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:MODE
Sets or queries the identifier enable/disable condition, which is one of the ID
OR conditions, for CAN bus signal triggering.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:MFORmat
Sets or queries the ID frame format (standard or extended), which is one of
the ID OR conditions, for CAN bus signal triggering.
5-253
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:IDENtifier:PFORmat
Sets or queries the ID input format, which is one of the ID OR conditions, for
CAN bus signal triggering.
5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:MSIGnal<x>:MESSage:IT
EM
Sets the message item, which is one of the ID OR conditions, for CAN bus
signal triggering.
5-254
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDOR:RTR
Sets or queries the RTR value, which is one of the ID OR conditions, for
CAN bus signal triggering.
5-254
5.1 List of Commands
