YOKOGAWA DLM4038 - Page 75

5-42
IM DLM4038-17EN
Command Function Page
:TRIGger:ACTion:MAIL:COUNt
Sets or queries the upper limit of email notifications that are sent when
trigger conditions are met.
5-247
:TRIGger:ACTion:MAIL:MODE
Sets or queries whether or not the DLM4000 will send email notification as
an action.
5-247
:TRIGger:ACTion:SAVE
Sets or queries whether or not the DLM4000 will save waveform data to the
storage medium as an action when trigger conditions are met (on/off).
5-247
:TRIGger:ACTion:STARt
Starts the action-on-trigger operation. 5-247
:TRIGger:ACTion:STOP
Stops the action-on-trigger operation. 5-247
:TRIGger:ADB?
Queries all A Delay B trigger settings. 5-247
:TRIGger:ADB:DELay
Sets or queries the for condition B for the A Delay B trigger. 5-247
:TRIGger:{ATRigger|BTRigger}?
Queries all trigger condition settings. 5-247
:TRIGger{[:ATRigger]|:BTRigger}
:CAN?
Queries all CAN bus signal trigger settings. 5-247
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:BRATe
Sets or queries the CAN bus signal trigger bit rate (data transfer rate). 5-247
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:EFRame?
Queries all CAN bus signal trigger error settings. 5-247
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:EFRame:CRC
Sets or queries the CAN bus signal trigger CRC error setting. 5-247
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:EFRame[:MODE]
Sets or queries the CAN bus signal trigger error frame setting. 5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:EFRame:STUFF
Sets or queries the CAN bus signal trigger stuff error setting. 5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN:IDData?
Queries all ID and data condition settings for CAN bus signal triggering. 5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:ACK?
Queries all ACK settings for the ID and data conditions for CAN bus signal
triggering.
5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:ACK:MODE
Sets or queries the ACK mode, which is one of the ID and data conditions,
for CAN bus signal triggering.
5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:ACK:TYPE
Sets or queries the ACK condition, which is one of the ID and data
conditions, for CAN bus signal triggering.
5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA?
Queries all data settings for the ID and data conditions for CAN bus signal
triggering.
5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:CONDition
Sets or queries the comparison condition, which is one of the ID and data
conditions, for CAN bus signal triggering.
5-248
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:DECimal<x>
Sets a reference value, which is one of the ID and data conditions, for CAN
bus signal triggering in decimal notation.
5-249
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:DLC
Sets or queries the data length code (DLC), which is one of the ID and data
conditions, for CAN bus signal triggering.
5-249
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:ENDian
Sets or queries the byte order of the reference values, which is one of the ID
and data conditions, for CAN bus signal triggering.
5-249
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:HEXa<x>
Sets a reference value, which is one of the ID and data conditions, for CAN
bus signal triggering in hexadecimal notation.
5-249
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:MODE
Sets or queries the data enable/disable condition, which is one of the ID and
data conditions, for CAN bus signal triggering.
5-249
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:MSBLsb
Sets or queries the MSB and LSB bits for the data, which is one of the ID
and data conditions, for CAN bus signal triggering.
5-249
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:PATTern<x>
Sets or queries the data value, which is one of the ID and data conditions, for
CAN bus signal triggering in binary notation.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:PFORmat
Sets or queries the data input format, which is one of the ID and data
conditions, for CAN bus signal triggering.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:DATA:SIGN
Sets or queries whether signed or unsigned data format will be used, which
is one of the ID and data conditions, for CAN bus signal triggering.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier?
Queries all identifier settings for the ID and data conditions for CAN bus
signal triggering.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier:ID?
Queries all ID settings for the ID and data conditions for CAN bus signal
triggering.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier:ID:HE
Xa
Sets the ID value, which is one of the ID and data conditions, for CAN bus
signal triggering in hexadecimal notation.
5-250
:TRIGger{[:ATRigger]|:BTRigger}
:CAN[:IDData]:IDENtifier:ID:MO
DE
Sets or queries the ID enable/disable condition, which is one of the ID and
data conditions, for CAN bus signal triggering.
5-250
5.1 List of Commands
