YOKOGAWA DLM4038 User Manual

5-49
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:DBYTe
Sets or queries the specified number of data bytes for I
2
C bus signal
triggering.
5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:HEXa<x>
Sets the data for I
2
C bus signal triggering in hexadecimal notation. 5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:MODE
Sets or queries the data condition enable/disable mode for I
2
C bus signal
triggering.
5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:PATTern<x>
Sets or queries the data value, which is one of the data conditions, for I
2
C
bus signal triggering in binary notation.
5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:ADDRess:DATA:PFORmat
Sets or queries the data input format, which is one of the data conditions, for
I
2
C bus signal triggering.
5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:GENeralcall?
Queries all general call settings for I
2
C bus signal triggering. 5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:GENeralcall:BIT7Maddress?
Queries all general call's 7-bit master address settings for I
2
C bus signal
triggering.
5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:GENeralcall:BIT7Maddress:H
EXa
Sets the general cal's 7-bit master address for I
2
C bus signal triggering in
hexadecimal notation.
5-273
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:GENeralcall:BIT7Maddress:P
ATTern
Sets or queries the general call's 7-bit master address for I
2
C bus signal
triggering in binary notation.
5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:GENeralcall:SBYTe
Sets or queries the general call's second byte type for I
2
C bus signal
triggering.
5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:INCLuderw
Sets or queries the on/off status of the R/W address bit in I
2
C bus signal
triggering.
5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:MODE
Sets or queries the trigger type for I
2
C bus signal triggering. 5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:NONack?
Queries all NON ACK ignore mode settings for I
2
C bus signal triggering. 5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:NONack:HSMode
Sets or queries whether or not NON ACK will be ignored in high-speed mode
for I
2
C bus signal triggering.
5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:NONack:READaccess
Sets or queries whether or not NON ACK will be ignored in read access
mode for I
2
C bus signal triggering.
5-274
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:NONack:STARtbyte
Sets or queries whether or not NON ACK will be ignored in start bytes for I
2
C
bus signal triggering.
5-275
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:SCL
Sets or queries the clock signal for I
2
C bus signal triggering. 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:I2C:SDA
Sets or queries the data signal for I
2
C bus signal triggering. 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:LIN?
Queries all LIN bus signal trigger settings. 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:BLENgth
Sets or queries the LIN bus signal trigger break length. 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:BRATe
Sets or queries the LIN bus signal trigger bit rate (data transfer rate). 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:ERRor?
Queries all LIN bus signal trigger error settings. 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:ERRor:PARity
Sets or queries the LIN bus signal trigger parity error setting. 5-275
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:ERRor:SYNCh
Sets or queries the LIN bus signal trigger synch error setting. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData?
Queries all ID and data settings for LIN bus signal triggering. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA?
Queries all LIN bus signal trigger data settings. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:CONDition
Sets or queries the data conditions for LIN bus signal triggering. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:DBYTe
Sets or queries the number of data bytes for LIN bus signal triggering. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:DECimal<x>
Sets the data for LIN bus signal triggering in decimal notation. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:ENDian
Sets or queries the data endian setting for LIN bus signal triggering. 5-276
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:HEXa<x>
Sets the data for LIN bus signal triggering in hexadecimal notation. 5-277
5.1 List of Commands
