Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:MODE
Sets or queries the data enable/disable condition for LIN bus signal
triggering.
5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:MSBLsb
Sets or queries the data MSB and LSB bits for LIN bus signal triggering. 5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:PATTern<x>
Sets or queries the data value for LIN bus signal triggering in binary notation. 5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:PFORmat
Sets or queries the input format, which is one of the data conditions, for LIN
bus signal triggering.
5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:DATA:SIGN
Sets or queries whether signed or unsigned data format will be used, which
is one of the data conditions, for LIN bus signal triggering.
5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:IDENtifier?
Queries all LIN bus signal trigger identifier settings. 5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:IDENtifier:ID?
Queries all LIN bus signal trigger ID settings. 5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:IDENtifier:ID:HEXa
Sets the ID for LIN bus signal triggering in hexadecimal notation. 5-277
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:IDENtifier:ID:MODE
Sets or queries the ID enable/disable condition, which is one of the ID and
data conditions, for LIN bus signal triggering.
5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:IDENtifier:ID:PATTe
rn
Sets or queries the ID value for LIN bus signal triggering in binary notation. 5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDData:IDENtifier:PFORmat
Sets or queries the ID input format, which is one of the ID and data
conditions, for LIN bus signal triggering.
5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR?
Queries all IDOR condition settings for LIN bus signal triggering. 5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier?
Queries all IDOR condition ID settings for LIN bus signal triggering. 5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier:ID<x>?
Queries an ID value, which is one of the IDOR condition settings, for LIN bus
signal triggering.
5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier:ID<x>:HEXa
Sets the ID value, which is one of the IDOR conditions, for LIN bus signal
triggering in hexadecimal notation.
5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier:ID<x>:MODE
Sets or queries the ID enable/disable condition, which is one of the IDOR
conditions, for LIN bus signal triggering.
5-278
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier:ID<x>:PATT
ern
Sets or queries the ID pattern, which is one of the IDOR conditions, for LIN
bus signal triggering in binary notation.
5-279
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier:MODE
Sets or queries the ID enable/disable condition for LIN bus signal triggering. 5-279
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:IDOR:IDENtifier:PFORmat
Sets or queries the ID input format, which is one of the IDOR conditions, for
LIN bus signal triggering.
5-279
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:MODE
Sets or queries the LIN bus signal trigger mode setting. 5-279
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:SOURce
Sets or queries the LIN bus signal trigger source signal. 5-279
:TRIGger{[:ATRigger]|:BTRigger}
:LIN:SPOint
Sets or queries the LIN bus signal trigger sample point. 5-279
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern?
Queries all state trigger settings. 5-279
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:CHANnel<x>
Sets or queries the state of a channel for state triggering. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:CLOCk?
Queries all clock signal settings for state triggering. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:CLOCk:SLOPe
Sets or queries the clock signal slope for state triggering. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:CLOCk:SOURce
Sets or queries the clock signal for state triggering. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:CONDition
Sets or queries the trigger condition for state triggering. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:LOGic
Sets or queries the combination condition for state triggering. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:{PODA|PODB|PODL}?
Queries all the settings for the state trigger logic input. 5-280
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:{PODA|PODB|PODL}:HEXa
Sets the logic input state of the state trigger in hexadecimal notation. 5-281
5.1 List of Commands
