YOKOGAWA DLM4038 User Manual

5-51
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:PATTern:{PODA|PODB|PODL}:PATTe
rn
Sets or queries the logic input state of the state trigger with a pattern. 5-281
:TRIGger{[:ATRigger]|:BTRigger}
:QUALify?
Queries all edge qualify trigger settings. 5-281
:TRIGger{[:ATRigger]|:BTRigger}
:QUALify:CHANnel<x>
Sets or queries the conditions for a waveform for edge qualified triggering. 5-281
:TRIGger{[:ATRigger]|:BTRigger}
:QUALify:CONDition
Sets or queries the trigger source qualify conditions for edge qualified
triggering.
5-281
:TRIGger{[:ATRigger]|:BTRigger}
:SENT?
Queries all SENT signal trigger settings. 5-281
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CEFactor?
Queries all SENT signal trigger error factor settings. 5-281
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CEFactor:SAComm?
Queries all status and communication error factor settings of SENT signal
triggering.
5-281
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CEFactor:SAComm:BIT<x>
Sets or queries status and communication error factor bit of SENT signal
triggering.
5-281
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CEFactor:SCPulses
Sets or queries the consecutive calibration pulse error factor of SENT signal
triggering.
5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CRCType
Sets or queries the SENT signal trigger CRC computation type. 5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CTICk
Sets or queries the SENT signal trigger clock tick value. 5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:CTOLerance
Sets or queries the SENT signal trigger clock tolerance. 5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:DNIBbles
Sets or queries the number of data nibbles for SENT signal analysis. 5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:DTYPe
Sets or queries the SENT signal trigger fast channel data format. 5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor?
Queries all SENT signal trigger error settings. 5-282
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor:FCRC
Sets or queries the SENT signal trigger fast channel CRC error. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor:NDValue
Sets or queries the SENT signal trigger nibble data value error. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor:NNUMber
Sets or queries the SENT signal trigger nibble data count error. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor:SAComm
Sets or queries the SENT signal trigger status and communication error. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor:SCRC
Sets or queries the SENT signal trigger slow channel CRC error. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:ERRor:SCPulses
Sets or queries the SENT signal trigger consecutive calibration pulse error. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa?
Queries all fast channel data settings for SENT signal triggering. 5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DATA<x>?
Queries all settings related to the specified user data of the SENT signal
trigger fast channel.
5-283
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DATA<x>:CONDition
Sets or queries the comparison condition of the specified user data of the
SENT signal trigger fast channel.
5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DATA<x>:DECimal<y>
Sets or queries the data of the specified user data of the SENT signal trigger
fast channel in decimal notation.
5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DATA<x>:MODE
Sets or queries the data enable/disable condition of the specified user data
of the SENT signal trigger fast channel.
5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DNIBbles?
Queries all fast channel nibble data settings for SENT signal triggering. 5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DNIBbles:CONDition
Sets or queries the nibble data comparison condition of the SENT signal
trigger fast channel.
5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DNIBbles:HEXa
Sets the SENT signal trigger fast channel nibble data in hexadecimal
notation.
5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DNIBbles:PATTern
Sets or queries the SENT signal trigger fast channel nibble data in binary
notation.
5-284
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:FDATa:DNIBbles:PFORmat
Sets or queries the data input format, which is one of the fast channel nibble
data conditions, for SENT signal triggering.
5-285
5.1 List of Commands
