1. Overview
31
TI 11B08A01-01E
(580) 400300
590
1100
(1280)
20
102 580 102
70 375410410410
30 674 (80)
A
505050
715 41030
(70)
430 20
(1605)
1801
(580)(190)
(800)
Liquid-sample
valve (LSV) *1
Liquid-sample
valve (LSV) *1
Liquid-sample
valve (LSV) *1
Standard isothermal oven
Standard isothermal oven
Standard isothermal oven
Holes for installation
4-ø10.5
Type 3 (Wall-mounting)
Weight: approx. 200 kg
Protection system A *1
*5
*4
*3
(435)
*3: Required clearance needed for wiring.
*4: It is recommended to mount at approx. 250 mm
above the floor for easy operation or
maintenance.
*5: The wall construction for mounting has to be
designed to withstand 4 times the analyzer’s
own weight.
Air outlet for stream switching valve
6 mm or 1/4” tube
Protective gas (instrumental air) inlet
Rc1/4 or 1/4NPT
Operation panel *1
Grounding wiring
(100 Ω or less)
Connection to electronics section *2
Wiring connection *2
Vent for protective gas (instrumental air)
Inlet/outlet for sample gas, carrier gases, etc.
6 mm or 1/4” tube
Unit: mm
Pressure gauge *1
Control unit
*1: It depends on specifications.
*2: Wiring connections are shown in
right figures.
View A
Vent header *1
(connection
Rc1/2 or
1/2NPT)
<Maintenance space>
(62)
28283529
(62) 36
36
125125
For TIIS
(wiring connection: G3/4)
For FM-X, CSA-X (wiring connection: 3/4NPT)
For FM-Y, CSA-Y (wiring connection: 3/4NPT)
For ATEX, IECEx, NEPSI (wiring connection: M25x1.5)
Connection 3/4NPT
Connection
G3/4
Connection G3/4
Connection 3/4NPT
Connection M25x1.5
For ATEX, IECEx, NEPSI (wiring connection: 3/4NPT)
Cable gland
Sealing fitting
(as accessories)
(for Ethernet cable)
Connection 3/4NPT
Sealing fitting
(as accessories)
(for Ethernet cable)
Cable gland
Cable gland
(as accessories)
For TIIS
(wiring connection: 3/4NPT)
Connection
3/4NPT
Cable gland
(as accessories)
Connection 3/4NPT
Connector
(as accessories)
Connector
(as accessories)
Connector
(as accessories)
(85)(85) 36
28
Protection system B *1
