1. Overview
32
TI 11B08A01-01E
M12 screw
25±5
*3: The four outer holes are used
for installation.
The height of M12 screw
(prepared by user) is 25 ±5 mm
from the floor.
*4: Required clearance needed for wiring.
(580) 400
300
590
(1280)
1100
20
430
580
410 410 410 375250
350
435
A
2051
(1855)
40 500
(580)(190)
(800)
27.5 300
(435)
Liquid-sample
valve (LSV) *1
Liquid-sample
valve (LSV) *1
Liquid-sample
valve (LSV) *1
Base
Standard
isothermal oven
Standard
isothermal oven
Standard
isothermal oven
Type 3 (Self-standing)
Weight: approx. 220 kg
Protection system A *1
Holes for installation
4-ø15 *3
*4
(435)
Air outlet for stream switching valve
6 mm or 1/4” tube
Protective gas (instrumental air) inlet
Rc1/4 or 1/4NPT
Operation panel *1
Grounding wiring
(100 Ω or less)
Connection to electronics section *2
Wiring connection *2
Vent for protective gas (instrumental air)
Inlet/outlet for sample gas, carrier gases, etc.
6 mm or 1/4” tube
Unit: mm
Pressure gauge *1
Control unit
*1: It depends on specifications.
*2: Wiring connections are shown in
right figures.
View A
Vent header *1
(connection
Rc1/2 or
1/2NPT)
<Maintenance space>
(62)
28283529
(62) 36
36
125125
For TIIS
(wiring connection: G3/4)
For FM-X, CSA-X (wiring connection: 3/4NPT)
For FM-Y, CSA-Y (wiring connection: 3/4NPT)
For ATEX, IECEx, NEPSI (wiring connection: M25x1.5)
Connection 3/4NPT
Connection
G3/4
Connection G3/4
Connection 3/4NPT
Connection M25x1.5
For ATEX, IECEx, NEPSI (wiring connection: 3/4NPT)
Cable gland
Sealing fitting
(as accessories)
(for Ethernet cable)
Connection 3/4NPT
Sealing fitting
(as accessories)
(for Ethernet cable)
Cable gland
Cable gland
(as accessories)
For TIIS
(wiring connection: 3/4NPT)
Connection
3/4NPT
Cable gland
(as accessories)
Connection 3/4NPT
Connector
(as accessories)
Connector
(as accessories)
Connector
(as accessories)
(85)(85) 36
28
Protection system B *1
Sep. 07, 2017-00
