YOKOGAWA GC8000 User Manual

1. Overview
36
TI 11B08A01-01E
M12 screw
25±5
*3: The four outer holes are used
for installation.
The height of M12 screw
(prepared by user) is 25 ±5 mm
from the floor.
*4: Required clearance needed for wiring.
(580) 400
300
590
(1280)
1100
20
580
250 375560560
430
1941
(1745)
A
27.5
(580)(190)
(800)
(435)
300
50040
Liquid-sample
valve (LSV) *1
Liquid-sample
valve (LSV) *1
Large isothermal oven
Large isothermal oven
Type 5 (Self-standing)
Weight: approx. 195 kg
Protection system A *1
Holes for installation
4-ø15 *3
*4
(435)
Air outlet for stream switching valve *1
6 mm or 1/4” tube
Protective gas (instrumental air) inlet
Rc1/4 or 1/4NPT
Protective gas (instrumental air for FPD2) inlet
Rc1/4 or 1/4NPT
Operation panel *1
Grounding wiring
(100 Ω or less)
Connection to electronics section *2
Wiring connection *2
Vent for protective gas (instrumental air)
Inlet/outlet for sample gas, carrier gases, etc.
6 mm or 1/4” tube
Unit: mm
Pressure gauge *1
Control unit
*1: It depends on specifications.
*2: Wiring connections are shown in
right figures.
View A
Vent header *1
(connection
Rc1/2 or
1/2NPT)
<Maintenance space>
28283529
For FM-X, CSA-X (wiring connection: 3/4NPT)
For FM-Y, CSA-Y (wiring connection: 3/4NPT)
For ATEX, IECEx, NEPSI (wiring connection: M25x1.5)
Connection 3/4NPT
Connection 3/4NPT
Connection M25x1.5
For ATEX, IECEx, NEPSI (wiring connection: 3/4NPT)
Connection 3/4NPT
Connector (as accessories)
28
Protection system B *1
Sep. 07, 2017-00
