YOKOGAWA SMARTDAC+ GP10 User Manual

General
Specications
GX90XA/GX90XD/GX90YD/
GX90WD/GX90XP
I/O Modules
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
GS 04L53B01-01EN
GS 04L53B01-01EN
©Copyright April 2014
7th Edition Nov. 10, 2015
 OVERVIEW
I/O modules are connected to the GX/GP, Expandable
I/O unit, GM main unit, and GM sub unit.
● Amoduletypeisvetypes,ananaloginput,a
digital input, a digital output, a digital input/output
and a pluse input.
● Inputandoutputhavemodulestructureanditcan
extendthemeasily.
● TheGX90XAanaloginputmoduleprovides
four types: (1) universal type that allows the
measurementinputforDCV(directvoltage),TC
(thermocouple),RTD(resistancetemperature
detector), and DI (contact or TTL level voltage), (2)
current input type with the built-in shunt resistor to
directlyinputastandardsignalof4-20mADC,(3)
electromagneticrelayscannertypeinsusceptible
tonoisesthatallowsthemeasurementinputfor
DCV,TC,andDI,and(4)lowwithstandvoltage
relaytypethatoffersalowcost.Ineachsystem,a
measurementinputsignalcanbeassignedtoeach
channel.
● TheGX90XDdigitalinputmodule,whichallowsup
to 16 digital inputs or pulse inputs, can be used as
amultipointdigitalinputorpluseinput.Thismodule
canalsobeusedasaremotecontrolinput.
● TheGX90YDdigitaloutputmoduleisassignedasa
relayoutput(contactC)andisusedwhenanalarm
activates. It can also be used to turn the output on
andoffmanuallyusingthetouchpanel.
● TheGX90WDdigitalinput/outputmoduleprovides
eight digital inputs or pulse inputs and six relay
outputs.Whentherearesmallamountsofdigital
inputs and digital outputs, you do not need to
mounttwomodules.Thisenablesefcientchannel
conguration.
● GX90XPpulseinputmodulecanreceiveupto10
pulseinputs.Themaximuminputfrequencyis20
kHz.Themodulecanbeusedtointegratepulse
signalsfromowmetersorthelike.*
*Integrationrequiresthemathfunction(/MToption).
● EachmoduleprovidesaM3screwterminaland
clampterminal*.Also,theinputterminalcanbe
removedandmounted.Thisenableswiringworkto
becarriedoutefciently.
* GX90YDandGX90WDareonlyM3screw
terminal.
● Themeasuringaccuraciesnotedinthegeneral
specicationshaveamarginoferrorthattakes
intoaccounttheproduct'scomponentsandthe
equipmentusedforadjustmentandtesting.
However,theactualvaluescalculatedfromthe
accuracytestingdatauponshipmentofthe
instrumentfromthefactoryareasfollows.
Input Type Measuring accuracy*
1
(typical value*
2
)
DCV 20mV ±(0.01%ofrdg+5μV)
60mV ±(0.01%ofrdg+5μV)
6V(1-5V) ±(0.01%ofrdg+2mV)
TC
*3
R ±1.1°C
K ± (0.01% of rdg +0.2°C for 0.0
to 1370.0°C;
± (0.15% of rdg +0.2°C) for
-200.0 to 0.0°C
K
(-200 to
500°C)
±0.2°C for 0.0 to 500.0°C;
± (0.15% of rdg +0.2°C) for
-200.0 to 0.0°C
J ± 0.2°C for 0.0 to 1100.0 °C;
± (0.10% of rdg + 0.2 °C) for
-200.0 to 0.0 °C
T ± 0.2°C for 0.0 to 400.0°C;
± (0.10% of rdg + 0.2 °C) for
-200.0 to 0.0 °C
N ± (0.01% of rdg + 0.2°C) for 0.0
to 1300.0 °C;
± (0.22% of rdg + 0.2°C) for
-200.0 to 0.0 °C
RTD Pt100 ± (0.02% of rdg + 0.2°C)
Pt100
(high resolu-
tion)
± (0.02% of rdg + 0.16°C )
rdg:Readingvalue
*1 AppliestoGX90XA-10-U2,A/Dintegrationtime
16.67msormore,Generaloperatingconditions:
23±2ºC,55±10%RH,supplyvoltage90–132,
180–264VAC,powerfrequencywithin50/60
Hz±1%,warm-upof30minutesormore,no
vibrationsorotherhindrancestoperformance.
*2 Forthemeasuringaccuracy(guaranteed),
seethemodule’sgeneralspecications(GS
04L53B01-01EN).
*3 Thesevaluesdonotincludethereference
junctioncompensationaccuracy.
