Color
Setup Item Selectable Range or Options Default Value
Color 24 colors (red, green, blue, blue violet, brown,
orange, yellow-green, light blue, violet, gray,
lime, cyan, dark blue, yellow, light gray, purple,
black, pink, light brown, light green, dark gray,
olive, dark cyan, and spring green) and a user-
defined color (1 color)
—
Color
Set channel display colors. The colors apply to the trend display and bar graph display.
For instructions on how to set the user-defined color, see page 1-23 in section 1.2.3, “Setting
the Display”.
Zone
Setup Item Selectable Range or Options Default Value
Lower 0 to 95% 0
Upper 5 to 100% 100
LowerandUpper
Set these values when you want to divide the waveform displays of channels into
separate zones so that waveforms do not overlap. Set the Lower and Upper positions as
percentages of the maximum display width. Set Lower to a value less than Upper, and set
the zone width (Upper – Lower) to be 5% or greater.
For display examples, see page 1-23 in section 1.2.3, “Setting the Display”.
Scale
Setup Item Selectable Range or Options Default Value
Position GX20/GP20: Off,1,2,3,4,5,6,7,8,9,10
GX10/GP10: Off,1,2,3,4,5,6
1
Division 4, 5, 6, 7, 8, 9, 10, 11, 12, C10 10
Position
Set this to set the scale display position of the trend display. Set this to Off to not display
scales.
Division
Set the number of divisions to make with the main scale marks.
C10: The scale is equally divided into 10 sections by main scale marks, and scale values are
indicated at 0, 30, 50, 70, and 100% positions.
For scale display examples, see page 1-23 in section 1.2.3, “Setting the Display”.
Bar graph
Setup Item Selectable Range or Options Default Value
Base position Lower, Center, Upper Lower
Division 4, 5, 6, 7, 8, 9, 10, 11, 12 10
Base position
Set the bar graph base position. This setting is applied on the bar graph display and when
you are displaying the current value on the scale as a bar graph on the trend displays.
For bar graph display examples, see page 1-23 in section 1.2.3, “Setting the Display”.
Division
Set the number of divisions to make with the main scale marks.
1.6ConfiguringMathChannels(/MToption)
