ZeeVee ZyPerUHD60 - Wallplate Encoder (Rev 1 WE): Enclosure

ZyPerUHD60
Important USB-C information:
To ensure proper operation when using the USB-C input for video and/or USB-Host function
and/or USB charging the USB-C cable must meet certain requirements.
USB-C Cable Requirements
1. Cable should be as short as possible
2. Must have USB-IF certification
3. Must be USB 3.2 Gen2 (2x1 or 2x2)
4. Current rating of 5A
5. Must support USB power delivery of 100W, 20V/5A
6. Data specs must be 20Gbp/s per lane (4K@60Hz) or above. (40Gbp/s cable)
7. USB Data specs must be 5Gbps (USB 3.0)
8. Must have built in E-Mark IC
Please see Appendix 1 near the end of this document for a list of known good USB-C cables.
ZeeVee is not responsible for damage to any equipment caused by poor or incorrect
USB-C cables.
HDMI Input
#1
F
HDMI 2.0a input port capable of up to 4KP60 4:4:4 with embedded audio and
HDCP 2.3 encryption.
HDMI Input
#2
G
HDMI 2.0a input port capable of up to 4KP60 4:4:4 with embedded audio and
HDCP 2.3 encryption.
HDMI
Output
H
HDMI loop-out of video/audio received on active input port. (Either HDMI or
USB-C)
Audio In/
Out
I
Audio Input/Output connector. Input/Output of balanced stereo audio on
Phoenix connector.
USB Host
J
USB 2.0 Host port. Configuration and routing of USB handled by the ZyPer
Management Platform configuration. Use this port for USB if HDMI is used for
video input.
Index
Definition
Port Name
Rev: 20231115
Page of 11 77
