Physical and Environmental
The following parameters apply to all encoders and decoders unless specifically stated
otherwise.
100-1240VAC 50-60Hz 0.7-0.45A draw on AC Mains
Output Max: 12VDC 2.0A
Output Max: 20VDC 6.0A (1WE, 2E, 2EA and 2EMP models only)
Encoder power
consumption
7-8W
Powered via either PoE or power adapter.
Power consumption of 1WE, 2E, 2EA and 2EMP up to additional 60W if
supplying power out the USB-C port.
Decoder power
consumption
7-8W in normal operation. Up to 18W max if powering USB devices.
Powered via either PoE or power adapter.
Encoder/Decoder: 215mm Wide x 120mm Deep x 25mm High
Wall-plate Encoder: Standard 2-Gang box size
91mm Wide x 105.6mm High x 40mm Deep
0° C to +45° C (32° F to 113° F)
-20° C to +70° C (-4° F to +158° F)
10% to 90% (Non-Condensing)
HBM
+/- 8 kV (air-gap discharge)
+/- 4 kV (contact discharge)
