ZeeVee ZyPerUHD60 - Single LAN Decoder (Rev 1 D;1 DA): Front Ports

ZyPerUHD60
Wallplate Encoder (Rev 1WE)
The function of the encoder is to accept raw video images, encode, encrypt and format them for
transmission.
Enclosure
There is one size of the ZyPerUHD60 Wallplate Encoder unit enclosure
Input Function
Box Size
HDMI and USB-C Video Inputs
Standard 2-Gang box (90mm Wide x 105.6mm High x 47mm Deep)
Rev: 20231115
Page of 17 77
User Manual
