HDMI 2.0a output port capable of up to 4KP60 4:4:4 with
embedded audio and HDCP 2.3 encryption.
Audio Output connector. Output of balanced stereo audio on
Phoenix connector.
RS232 Control Port for sending and receiving side-band serial
traffic to/from decoders as directed by ZMP.
Infrared Commands to be passed TO Encoders as configured by
ZMP.
Infrared Commands information passed FROM Encoders to
Decoders as configured by ZMP. Max current 330mA.
LED illuminated when unit is powered. (Green)
LED Illuminated when active video is being processed. (Green)
2 ports of USB 2.0 Type-A connectivity. Either port may be used
and both operate simultaneously. Each port may provide up to
1.0A of power output.
