Zeiss Axiotech - Page 35

Axiotech and Axiotech
vario
Carl Zeiss
B 40-020 e 06/99 1-21
HBO 50 mercury pressure short-arc lamp
lamp voltage for lamp types L1 and L2........................................................L1: 39...45 V/L2: 34...39 V
lamp current for lamp types L1 and L2............................................................... L1: 1.30 A/L2: 1.45 A
output .......................................................................................................................................50 W
average light current............................................................................................................. 2000 lm
average life...............................................................................................................................100 h
luminous area ............................................................................................................... 0.3 × 1.0 mm
N XBO 75 Xenon short-arc lamp
average life of OSRAM XBO 75 W/2 lamp..................................................................................400 h
average life of HAMAMATSU Xenon lamp...............................................................................2000 h
Optical/mechanical data
Stand with stage focusing............................................................................with coarse drive (2 mm/rot)
....................................................................................................................and fine drive (0.2 mm/rot)
....................................................................................................................fine scaling 2 µm/increment
....................................................................................................................overall lifting range: 25 mm
Objective change.......................................................................................manually via 5x HD nosepiece
Objectives.........................................................................ICS-HD objective line with M 27 × 0.75 thread
....................................................................................... ICS-H objective line with W 0.8″ × 1/36″thread
....................................................................................................... and adapter H "0" M 27 for W 0.8″
Eyepieces with plug-in diameter...................................................................................................30 mm
and field number 23.................................................................................... W-PL 10×/23 Br. foc.
Object stages (selection);
reflected-light mechanical stage 75 × 50 R;
dimensions (width × depth)..................................................................................... 160 × 140 mm
travel range................................................................................................................ 75 × 50 mm
reflected-light mechanical stage 75 × 50/240°R;
dimensions (width × depth)..................................................................................... 160 × 140 mm
travel range................................................................................................................ 75 × 50 mm
Condensers:
ABBE condenser 0.9/1.25 with 5-position disk turret..........................................for objectives 5...50 ×
ABBE condenser 0.9/1.25..................................................................................for objectives 5...50 ×
swing-in condenser 0.9 Z Pol........................................................................for objectives 2.5...100 ×
achr. condenser 0.8 H.....................................................................................for objectives 5...100 ×
achr. condenser 0.8 H D Ph.............................................................................for objectives 5...100 ×
achr. switching condenser 0.5......................................................................for objectives 1.25...50 ×
