Carl Zeiss Axiotech and Axiotech
vario
3-16 B 40-020 e 06/99
☞
Polarizer and analyzer are firmly integrated in the reflector slider with the appropriate
orientation to each other.
• Place specimen on the stage, set the required magnification, focus and view the specimen in the
polarization contrast now present.
• To obtain color contrast of anisotropic specimen details, remove the dust protection insert ( 3-14/4)
and replace it with the Pol compensator (λ-sub) (3-14/6) which is inserted in the reflector slider from
the right. The color intensity can then be varied via the adjusting lever of the compensator.
☞
Adjustment of the lever on the compensator permits anisotropic specimens to be visualized
when non-rotary stages are used.
