ProFace X (DS) User Manual
Page | 9 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Note:
 Make sure whether the positive polarity and negative polarity of the DC 12V AC adapter is
connected correctly. A reverse connection may damage the device. It is not advisable to connect
the AC 24V AC adapter to the DC 12V input port.
 Make sure to connect the wires following the positive polarity and negative polarity shown on
the device's nameplate.
 The warranty service does not cover accidental damage, damage caused by misoperation, and
damage due to independent installation or repair of the product by the user.

ZKTeco ProFace X Specifications

General

Type	Face recognition terminal
IK code	IK04
Face capacity	30000
Product color	Black, Grey
User capacity	50000 user(s)
Event capacity	1000000
Wiegand interface	Yes
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
International Protection (IP) code	IP68
Operating temperature (T-T)	-30 - 60 °C
RS-232 ports	1
Screen shape	Flat
Display diagonal	8 \
Display technology	LED
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Input current	2 A
Input voltage	12 V

Weight and Dimensions

Depth (with stand)	26 mm
Width (with stand)	143 mm
Height (with stand)	227 mm
