ZKTeco ProFace X User Manual

ProFace X (DS) User Manual
Page | 49 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
7.6.2 Wiegand Output
Function Description
Function Name Descriptions
SRB
When SRB is being enabled, its lock is controlled by the SRB to prevent the
lock from opening due to device removal.
Wiegand Format
Its value can be 26 bits, 34 bits, 36 bits, 37 bits, and 50 bits.
Wiegand output bits
After selecting the required Wiegand format, select the corresponding output bit
digits from the Wiegand format.
Failed ID
If the verification fails, the system will send the failed ID to the device and replace
the card number or personnel ID with the new one.
Site Code
It is similar to the device ID. The difference is that a site code can be set manually
and is repeatable on a different device. The valid value ranges from 0 to 256 by
default.
Pulse Width(us)
The time width represents the changes in the quantity of electric charge with
regular high-frequency capacitance within a specified time.
Pulse Interval(us)
The time interval between pulses.
ID Type
Select the ID types as either User ID or card number.

ZKTeco ProFace X Specifications

General

Type	Face recognition terminal
IK code	IK04
Face capacity	30000
Product color	Black, Grey
User capacity	50000 user(s)
Event capacity	1000000
Wiegand interface	Yes
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
International Protection (IP) code	IP68
Operating temperature (T-T)	-30 - 60 °C
RS-232 ports	1
Screen shape	Flat
Display diagonal	8 \
Display technology	LED
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Input current	2 A
Input voltage	12 V

Weight and Dimensions

Depth (with stand)	26 mm
Width (with stand)	143 mm
Height (with stand)	227 mm
