ZKTeco ProFace X User Manual

ProFace X (DS) User Manual
Page | 86 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
16 Connect to ZKBiosecurity Software
Set the Communication Address 16.1
 Device side
1. Tap System settings > Network settings > TCP/IP settings in the main menu to set the IP
address and gateway of the device.
(NOTE: The IP address should be able to communicate with the ZKBioSecurity server, preferably in
the same network segment with the server address)
2. In the main menu, click System settings > Cloud server settings to set the server address and the
server port.
Server address: Set the IP address as of the ZKBioSecurity server.
Server port: Set the server port as of ZKBioSecurity (The default is 6609).

ZKTeco ProFace X Specifications

General

Type	Face recognition terminal
IK code	IK04
Face capacity	30000
Product color	Black, Grey
User capacity	50000 user(s)
Event capacity	1000000
Wiegand interface	Yes
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
International Protection (IP) code	IP68
Operating temperature (T-T)	-30 - 60 °C
RS-232 ports	1
Screen shape	Flat
Display diagonal	8 \
Display technology	LED
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Input current	2 A
Input voltage	12 V

Weight and Dimensions

Depth (with stand)	26 mm
Width (with stand)	143 mm
Height (with stand)	227 mm
