ZKTeco ProFace X User Manual

ProFace X (DS) User Manual
Page | 46 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Cloud Server Setting 7.5
Tap Cloud Server Setting on the Comm. Settings interface to connect with the ADMS server.
Function Description
Function Name Description
Enable
Domain
Name
Server Address
Once this mode is turned ON, the domain name mode "http://... "
will be used, such as http://www.XYZ.com, while "XYZ" denotes the
domain name.
Disable
Domain
Name
Server Address
The IP address of the ADMS server.
Server Port
Port used by the ADMS server.
Enable Proxy Server
The IP address and the port number of the proxy server is set
manually when the proxy is enabled.
HTTPS
Based on HTTP, transmission encryption and identity
authentication ensures the security of the transmission process.
Wiegand Setup 7.6
It is used to set the Wiegand input and output parameters.
Tap Wiegand Setup on the Comm. Settings interface to set up the Wiegand input and output parameters.

ZKTeco ProFace X Specifications

General

Type	Face recognition terminal
IK code	IK04
Face capacity	30000
Product color	Black, Grey
User capacity	50000 user(s)
Event capacity	1000000
Wiegand interface	Yes
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
International Protection (IP) code	IP68
Operating temperature (T-T)	-30 - 60 °C
RS-232 ports	1
Screen shape	Flat
Display diagonal	8 \
Display technology	LED
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Input current	2 A
Input voltage	12 V

Weight and Dimensions

Depth (with stand)	26 mm
Width (with stand)	143 mm
Height (with stand)	227 mm
