ZKTeco ProFace X User Manual

ProFace X (DS) User Manual
Page | 45 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
Adding WIFI Network Manually
The WIFI can also be added manually if the required WIFI does not show on the list.
Note: After successfully adding the WIFI manually, follow the same process to search for the added
WIFI name. Click here
to view the process to search the WIFI network.
Advanced Setting
On the Wireless Network interface, tap on Advanced to set the relevant parameters as required.
Function Description
Function Name Description
DHCP
Dynamic Host Configuration Protocol (DHCP) dynamically allocates IP addresses
to network clients. If the DHCP is enabled, then the IP cannot be set manually.
IP Address
The IP address for the WIFI network, the default is 0.0.0.0. It can be modified
according to the network availability.
Subnet Mask
The default Subnet Mask of the WIFI network is 255.255.255.0. It can be modified
according to the network availability.
Gateway
The Default
Gateway address is 0.0.0.0. It can be modified according to the
network availability.
Tap on Add WIFI Network to add
the WIFI manually.
On this interface, enter the WIFI
network parameters. (The added
network must exist.)

ZKTeco ProFace X Specifications

General

Type	Face recognition terminal
IK code	IK04
Face capacity	30000
Product color	Black, Grey
User capacity	50000 user(s)
Event capacity	1000000
Wiegand interface	Yes
Temperature measurement range	34 - 45 °C
Temperature measurement accuracy	0.3 °C
Temperature measurement distance	30 - 50 cm
International Protection (IP) code	IP68
Operating temperature (T-T)	-30 - 60 °C
RS-232 ports	1
Screen shape	Flat
Display diagonal	8 \
Display technology	LED
Sensor type	CMOS
Camera resolution (numeric)	2 MP
Input current	2 A
Input voltage	12 V

Weight and Dimensions

Depth (with stand)	26 mm
Width (with stand)	143 mm
Height (with stand)	227 mm
