2.5.6 Connecng to an auxiliary device = AUX 1 - Dry contact provided for disconnecon from the 230V
power supply
The chlorinator manages a dry contact calibrated for disconnecon from the 230V power supply. The power
supply is separated with its own protecon (circuit breaker calibrated to suit the equipment controlled or its
transformer – max. 8 A).
Preferred connecon for NL LED spotlights.
Possible controls: ON/OFF with mer for all monochromac spotlights, ON/OFF/Colour with NL RGBW LED
spotlights
230 V contact
All types of auxiliary
device
230 V
Transformer for lighng,
booster pump, etc.
maximum 8 A
Preferred connecon for Zodiac® NL LED spotlights (see
installaon manual)
: 230 VAC / 12 VAC
(50/60 Hz) transformer
: Electrical protecon
: Auxiliary relay for
external controller or
switch
With 2 spotlights
With 1 spotlight
