16
2.5.7 Connecng to a heang system = AUX2 - 12-24V
12 - 24 V contact
All types of auxiliary
device
12 - 24 V
Heang system
with remote on/o control
1. use an appropriate length of a 2 x 0.75 mm²
cable (not supplied).
2. Use this cable to connect the appliance contact
(AUX2) to the remote on/o control of the
heang system (see connecon details in the
associated installaon manual).
3. Turn the heang system on. Set the
temperature setpoint of the heang system to
its maximum (and set to the desired mode if
there are several heang modes are available).
The chlorinator will use the water temperature
measured by its sensor to manage the acvaon
of the heang system according to the
temperature setpoint.
1
2
AUX 2 (12-24 V)
A = Chlorinator
B = Heang system
A
Connecon of a heang system
with remote on/o control
2 x 0.75 mm
Heang system
without remote on/o control
1. use an appropriate length of a 2 x 0.75 mm² cable
(not supplied).
2. Disconnect one of the 2 ow switch (D) wires from
the terminal block of the heang system (B) (refer to
the manual if necessary).
3. Connect the wire from terminal 1 of the
chlorinator (A) in place of the ow switch (D) wire
that was disconnected from the terminal block of
the heang system (B).
4. Connect the disconnected ow switch wire (step
2) with the wire from terminal 2 of the chlorinator
(A) using a suitable connecon terminal (C).
5. Turn the heang system on. Set the temperature
setpoint of the heang system to its maximum
(and set to the desired mode if there are several
heang modes are available). The chlorinator will
use the water temperature measured by its sensor
to manage the acvaon of the heang system
according to the temperature setpoint.
1
2
AUX 2 (12-24 V)
A = Chlorinator
B = Heang
system
C = Connecon
terminal block
D = Flow switch
A
Connecon of a heang system
without remote on/o control
2 x 0.75 mm
