Zoom PodTrak P4 User Manual

Explanation of terms
Audio interface
The
P4
enables sounds from mics and instruments, for example, to be input to a computer, smartphone
or tablet. It can also output sounds from that device to speakers and headphones.
USB audio return
When the
P4
is connected as an audio interface, this is the signal output from the computer, smartphone
or tablet. Background music can be played from the connected device.
SOUND PAD buttons
Audio les can be assigned to these. Press one to play the assigned le. These are convenient to play
opening and closing music, jingles, and interviews that have been recorded in advance.
USB Mix Minus
When using the
P4
as an audio interface, this can prevent feedback to a person participating in a call
through the connected device.
Podcasting
This is one way to share audio les publicly on the Internet. Podcasters make contents and distribute
them via the Internet so people can listen easily on smartphones, computers and other devices.
Dynamic mic
This type of mic does not require phantom power and is strong and durable.
Condenser mic
This type of mic usually has high sensitivity and can capture audio with high quality. Phantom power
supply is necessary for use.
11

Zoom PodTrak P4 Specifications

Audio Specifications

number of input channels	4 (mono/stereo)
number of output channels	1 (headphone × 4)
phantom power	+48 V

Ports & Interfaces

connectors	MIC XLR jacks (2: HOT)
smartphone connection jack	TRRS mini jack (4 contacts, TIP: L, RING1: R, RING2: GND, SLEEVE: MIC)
USB	USB Type-C

Power

dc power supply	5 V USB Type-C
battery type	2 AA batteries (alkaline, NiMH or lithium)
ac adapter	DC 5 V/1 A

Battery Life

alkaline batteries operation time	about 4 hours
nimh batteries operation time	about 4.5 hours
lithium batteries operation time	about 9 hours

Weight and Dimensions

external dimensions	112 mm (W) × 155 mm (D) × 47 mm (H)
weight	290 g
