Zoom PodTrak P4 User Manual

Recording
The input signals of each channel, the sounds (stereo) played by pressing SOUND PAD buttons, and the
master channel signal (stereo) can be recorded simultaneously as separate les to the SD card.
Recording/recording paused: elapsed recording time
Recording stopped: available recording time
REC indicator
1.
Press when the Home Screen is open.
Recording will start and the REC indicator will light red.
Press
when recording to pause recording. (The REC indicator will blink). Press again to
resume recording.
2.
Press or .
Recording will stop.
HINT
•When the channel 3 INPUT SELECT switch is set to
or the channel 4 INPUT SELECT switch is set to
, those channels will record in stereo.
•If you do not want to record a channel or you want to turn its input off temporarily, press to mute
it.
•Recorded les will be named with the date and time when recording started.
•See “P4 folder and le structure” on page 32 for the location where recorded les are saved.
25

Zoom PodTrak P4 Specifications

Audio Specifications

number of input channels	4 (mono/stereo)
number of output channels	1 (headphone × 4)
phantom power	+48 V

Ports & Interfaces

connectors	MIC XLR jacks (2: HOT)
smartphone connection jack	TRRS mini jack (4 contacts, TIP: L, RING1: R, RING2: GND, SLEEVE: MIC)
USB	USB Type-C

Power

dc power supply	5 V USB Type-C
battery type	2 AA batteries (alkaline, NiMH or lithium)
ac adapter	DC 5 V/1 A

Battery Life

alkaline batteries operation time	about 4 hours
nimh batteries operation time	about 4.5 hours
lithium batteries operation time	about 9 hours

Weight and Dimensions

external dimensions	112 mm (W) × 155 mm (D) × 47 mm (H)
weight	290 g
