Zoom PodTrak P8 User Manual

Preparing for use
Inserting SD cards
SD card slot
1.
With the power off, open the SD card slot cover, and insert an SD card all the way into the slot.
To remove an SD card, push it further into the slot and then pull it out.
NOTE
•Cards that conform to SDHC and SDXC specications are supported.
•Disable write-protection on the SD card before inserting it.
•Inserting or removing an SD card while the power is on could result in data loss.
•When inserting an SD card, be sure to insert the correct end with the top side up as shown.
•If an SD card is not loaded, recording and playback are not possible.
•Before using SD cards that have just been purchased or that have been formatted on a computer, they
must be formatted by the
P8
( “Formatting SD cards” on page 83).
17

Zoom PodTrak P8 Specifications

Power

phantom power	+48 V
battery type	4 AA batteries
ac adapter	DC 5 V/1 A

Ports & Interfaces

usb type	USB Type-C
headphones output	3.5mm stereo mini
speaker output	TRS jacks

Recording

recorder format	WAV 44.1kHz, 16-bit, mono/stereo
audio interface	44.1kHz, 16-bit, 2-in/2-out
supported media	4–32 GB cards (SDHC), 64–512 GB cards (SDXC)

Display

display type	full-color touchscreen LCD
display size	4.3 inches
display resolution	480×272

Weight and Dimensions

weight	1.43 kg
width	295 mm
depth	248 mm
height	61 mm
