Zoom PodTrak P8 User Manual

Mixer block diagram
48 V
MIC 1-5
GAIN A/D DC CUT
OFF AIR L
ON AIR L
ON AIR R
LEVEL METER
ON AIR
PHONE/BTA-2 OUT
REC DATA 1-5 to SD CARD
P8 MIXER BLOCK DIAGRAM
OFF AIR R
TONE
MUTE
DE-
ESSER
L R
2 3
D/A
1
REC DATA MASTER L to SD CARD REC DATA MASTER R to SD CARD
VOLUME
SOUND PAD
COMP
INPUT LEVEL METER
5 6 4
48 V
MIC 6/USB IN
GAIN
A/D
DC CUT
LEVEL METER
ON AIR
TONE/
TREBLE/
BASS
MUTE
DE-
ESSER
COMP
INPUT LEVEL METER
INPUT SEL
USB IN 2
USB IN 1
PHONE/BTA-2
LEVEL METER
ON AIR
TREBLE/
BASS
MUTE
A/D
DC CUT
LEVEL METER
ON AIR
PHONE L BACKUP
PHONE R BACKUP
VOLUME
USB IN 1 BACKUP USB IN 2 BACKUP
USB OUT L to PC USB OUT R to PC
KEEP TRACK FILES
REC DATA 7 L to SD CARD REC DATA 7 R to SD CARD REC DATA 8 L to SD CARD
REC DATA 8 R to SD CARD
KEEP TRACK FILES KEEP TRACK FILES
DIGITAL
GAIN
DIGITAL
GAIN
LOW
CUT
LOW
CUT
USB IN 1 BACKUP
USB IN 2 BACKUP
USB
MIX MINUS
VOLUME
OUTPUT
LIMITER
D/A
PAD A-I L ch PAD A-I R ch
LEVEL
FADER FADER FADER FADER
D/A
PHONE L BACKUP PHONE R BACKUP
ON AIR
HEADPHONE
OUTPUT LIMITER
REDUCTION
PAD A-I
SOUND PAD L
SOUND PAD R
MUTE
LIMITER
LIMITER
REC DATA 6 L to SD CARD REC DATA 6 R to SD CARD
Only enabled
for on air
NOISE
REDUCTION
NOISE
REDUCTION
Only enabled
for on air
-1 -1
OUTPUT LIMITER
REDUCTION
-1 -1
1/2
93

Zoom PodTrak P8 Specifications

Power

phantom power	+48 V
battery type	4 AA batteries
ac adapter	DC 5 V/1 A

Ports & Interfaces

usb type	USB Type-C
headphones output	3.5mm stereo mini
speaker output	TRS jacks

Recording

recorder format	WAV 44.1kHz, 16-bit, mono/stereo
audio interface	44.1kHz, 16-bit, 2-in/2-out
supported media	4–32 GB cards (SDHC), 64–512 GB cards (SDXC)

Display

display type	full-color touchscreen LCD
display size	4.3 inches
display resolution	480×272

Weight and Dimensions

weight	1.43 kg
width	295 mm
depth	248 mm
height	61 mm
