Zoom PodTrak P8 User Manual

Providing power
The
P8
can be powered by an AC adapter, USB bus power or batteries.
The order of power supply priority is AC adapter rst, USB bus power next, and batteries last.
Using an AC adapter
Connect the dedicated AC adapter (AD-14) cable to the DC IN 5V AC adapter connector and the adapter to
an outlet.
DC IN 5V AC adapter connector
Installing batteries
To run the
P8
on battery power, open the battery compartment cover on the bottom and install 4 AA
batteries.
Open while pressing up
NOTE
•Use only one type of battery (alkaline, NiMH or lithium) at a time.
•Set the type of battery used correctly so that the amount of remaining battery charge can be shown
accurately. ( “Setting the battery type” on page 76)
•The battery charge can be checked on the Home Screen ( page 15).
18

Zoom PodTrak P8 Specifications

Power

phantom power	+48 V
battery type	4 AA batteries
ac adapter	DC 5 V/1 A

Ports & Interfaces

usb type	USB Type-C
headphones output	3.5mm stereo mini
speaker output	TRS jacks

Recording

recorder format	WAV 44.1kHz, 16-bit, mono/stereo
audio interface	44.1kHz, 16-bit, 2-in/2-out
supported media	4–32 GB cards (SDHC), 64–512 GB cards (SDXC)

Display

display type	full-color touchscreen LCD
display size	4.3 inches
display resolution	480×272

Weight and Dimensions

weight	1.43 kg
width	295 mm
depth	248 mm
height	61 mm
