Zoom PodTrak P8 User Manual

Adjusting the brightness of the touchscreen
The brightness of the touchscreen can be adjusted.
1.
Tap the / / power button on the Home Screen.
2.
Slide to adjust the brightness of the touchscreen.
HINT
Double-tap the slider or the bar to reset it to the default value.
77

Zoom PodTrak P8 Specifications

Power

phantom power	+48 V
battery type	4 AA batteries
ac adapter	DC 5 V/1 A

Ports & Interfaces

usb type	USB Type-C
headphones output	3.5mm stereo mini
speaker output	TRS jacks

Recording

recorder format	WAV 44.1kHz, 16-bit, mono/stereo
audio interface	44.1kHz, 16-bit, 2-in/2-out
supported media	4–32 GB cards (SDHC), 64–512 GB cards (SDXC)

Display

display type	full-color touchscreen LCD
display size	4.3 inches
display resolution	480×272

Weight and Dimensions

weight	1.43 kg
width	295 mm
depth	248 mm
height	61 mm
