Zoom PodTrak P8 User Manual

Specications
Input and out-
put channels
Number of input channels Mic inputs: 6 (mono)
Smartphone input: 1 (stereo)
Number of output channels 2 (through 6 headphone and L/R speaker outputs)
Connectors Mic Type XLR jacks (2: HOT)
Input gain 0 – +70 dB
Input impedance 3 kΩ
Maximum input
level
+5 dBu (at 0 dBFS)
Phantom power +48 V
Smartphone
connection jack
Type TRRS mini jack
(4-contact/TIP: L, RING 1: R, RING 2: GND, SLEEVE: MIC)
Input impedance 3 kΩ
Maximum input
level
+2.5 dBu
USB USB Type-C (audio interface and mass storage functions)
• Use a USB cable that supports data transfer. USB bus power is supported.
Headphones Type 3.5 mm stereo mini
Maximum output
level
20 mW + 20 mW (32Ω load)
Output impedance 27 Ω
Speaker outputs Type TRS jacks (balanced)
Maximum output
level
+5.5 dBu
Output impedance 320 Ω
AC adapter Power supply connector for AD-14
Recorder Format WAV 44.1kHz, 16-bit, mono/stereo
Recording media 4–32GB cards compatible with the SDHC specication (class 10 or higher)
64–512GB cards compatible with the SDXC specication (class 10 or
higher)
Audio interface 44.1kHz, 16-bit, 2-in/2-out
Frequency response −1.0 dB: 20 Hz – 20 kHz at 44.1kHz sampling rate
Equivalent input noise –124 dBu or less (IHF-A) at +70dB/150Ω input
Display 4.3" (480×272) full-color touchscreen LCD
Power 4 AA batteries (alkaline, lithium, or rechargeable NiMH)
AC adapter (ZOOM AD-14): DC 5 V/1 A (supports USB bus power)
Estimated continuous operation time using batteries Recording 44.1kHz/16-bit/4ch audio to SD card (when +48 V is OFF and
headphone impedance is 32 Ω)
Alkaline batteries: about 2 hours
NiMH batteries (1900 mAh): about 3.5 hours
Lithium batteries: about 6.5 hours
•Theabovevaluesareapproximate.
•
Continuous battery operation times were determined using in-house test-
ing methods. They will vary greatly according to use conditions.
Power consumption 5 W
External dimensions 295 mm (W) × 248 mm (D) × 61 mm (H)
Weight (unit only) 1.43 kg
•0dBu=0.775V
92

Zoom PodTrak P8 Specifications

Power

phantom power	+48 V
battery type	4 AA batteries
ac adapter	DC 5 V/1 A

Ports & Interfaces

usb type	USB Type-C
headphones output	3.5mm stereo mini
speaker output	TRS jacks

Recording

recorder format	WAV 44.1kHz, 16-bit, mono/stereo
audio interface	44.1kHz, 16-bit, 2-in/2-out
supported media	4–32 GB cards (SDHC), 64–512 GB cards (SDXC)

Display

display type	full-color touchscreen LCD
display size	4.3 inches
display resolution	480×272

Weight and Dimensions

weight	1.43 kg
width	295 mm
depth	248 mm
height	61 mm
