Channel faders
These adjust channel signal levels in ranges from −∞ to +10 dB.
BTA-2 power supply connector
Use this power supply connector when connecting a BTA-2 wireless adapter.
Smartphone connection jack
Connect a smartphone here.
SOUND PAD A–I buttons
Use to play the sounds assigned to them.
SPEAKER OUT jacks
These output a stereo mix of the signals from all the channels. Connect them to a power amplier, a
PA system or speakers with built-in ampliers, for example.
PHONES jacks
These output a stereo mix of the signals from all the channels. Connect headphones to these.
PHONES knobs
Use to adjust the volumes of the signals output from the PHONES jacks.
USB OUT knob
Use to adjust the volume of the signal output from the USB port.
SPEAKER OUT knob
Use to adjust the volume of the signals output from the SPEAKER OUT jacks.
STOP button
Use to stop recording/playback.
REC button
Use to start/stop recording.
PLAY/PAUSE button
Use to play/pause recorded les.
MARK button
Press to add marks to recording les during recording/playback. These provide editing guides.
9
