GS-4012F User’s Guide
108 Chapter 15 Link Aggregation
15.1.2 Link Aggregation ID
LACP aggregation ID consists of the following information
1
:
15.2 Link Aggregation Status
Click Advanced Application, Link Aggregation in the navigation panel. The Link
Aggregation Control Protocol Status screen displays by default.
Figure 44 Link Aggregation Control Protocol Status
The following table describes the labels in this screen.
Table 27 Link Aggregation ID: Local Switch
SYSTEM PRIORITY MAC ADDRESS KEY PORT PRIORITY PORT NUMBER
0000 00-00-00-00-00 0000 00 0000
Table 28 Link Aggregation ID: Peer Switch
SYSTEM PRIORITY MAC ADDRESS KEY PORT PRIORITY PORT NUMBER
0000 00-00-00-00-00 0000 00 0000
1. Port Priority and Port Number are 0 as it is the aggregator ID for the trunk group, not the individual
port.
