GS-4012F User’s Guide
Chapter 24 OSPF 147
24.2 OSPF Status
To view current OSPF status, click IP Application, OSPF in the navigation panel to display
the screen as shown next.
Figure 63 OSPF Status
The following table describes the labels in this screen.
Table 50 OSPF Status
LABEL DESCRIPTION
OSPF This field displays whether OSPF is activated (Running) or not (Down).
Interface The text box displays the OSPF status of the interface(s) on the switch.
Neighbor The text box displays the status of the neighboring router participating in the OSPF
network.
Link State
Database
The text box displays information in the link state database which contains data in the
LSAs.
Poll Interval(s) The text box displays how often (in seconds) this screen refreshes. You may change
the refresh interval by typing a new number in the text box and then clicking Set
Interval.
Stop Click Stop to end OSPF status polling.
