Chapter 1 Introduction
ZyWALL USG Series User’s Guide
32
Figure 5 SSL VPN With Full Tunnel Mode
User-Aware Access Control
Set up security policies to restrict access to sensitive information and shared resources based on the user
who is trying to access it. In the following figure user A can access both the Internet and an internal file
server. User B has a lower level of access and can only access the Internet. User C is not even logged in,
so and cannot access either the Internet or the file server.
Figure 6 Applications: User-Aware Access Control
Load Balancing
Set up multiple connections to the Internet on the same port, or different ports, including cellular
interfaces. In either case, you can balance the traffic loads between them.
Figure 7 Applications: Multiple WAN Interfaces
Web Mail File Share
Web-based Application
https://
Application Server
Non-Web
LAN (192.168.1.X)
To Next Page
