Chapter 47 Diagnostics
ZyWALL USG Series User’s Guide
998
47.2.2 The Diagnostics Collect on AP Screen
This screen provides an easy way for you to generate a file containing the selected managed AP’s
configuration and diagnostic information. You may need to generate this file and send it to customer
support during troubleshooting. Click Maintenance > Diagnostics > Collect on AP to open the Collect on
AP screen.
Figure 711 Maintenance > Diagnostics > Collect on AP
Size This is the size of the most recently created diagnostic file.
Upload the cmd file as the
customized script
Select this to upload a customized shell script to display information about the Zyxel
Device. Use a text editor to create the shell script files. They must use a “.zysh”
filename extension. Specify the new name for the shell script file. Use up to 25
characters (including a-z, A-Z, 0-9 and ;‘~!@#$%^&()_+[]{}’,.=-). Spaces are allowed.
Copy the diagnostic file to
USB storage (if ready)
Select this to have the Zyxel Device create an extra copy of the diagnostic file to a
connected USB storage device.
Select Upload the cmd file as the customized script to display the following fields.
Shell Scripts
Filename This displays the names of the customized shell script you created.
Upload Shell Script
File Path Click Browse to find the location of the file you want to upload in this field. Click
Upload to begin the upload process. This process may take a few minutes.
Apply Click Apply to save your changes.
Collect Now Click this to have the Zyxel Device create a new diagnostic file.
Wait while information is collected.
Table 403 Maintenance > Diagnostics > Collect (continued)
LABEL DESCRIPTION
