Pannoramic MIDI 1.18 User’s Guide 1 Product Description
1.1.4 Base Unit
The following figure shows the main parts of the base unit.
Figure 2 – Main parts of base unit
1. Protective covers
2. Slide tray
3. Manual camera changer
4. AxioCam MRm Rev3 camera
5. CIS VCC-FC60FR19CL scan camera
• Flourescent option – A
6. HXP 120 fiber-coupled illumination unit (can be used with AxioCam MRm Rev3 and Stingray
cameras only)
7. HXP 120 illumination adapter and cable (use with AxioCam MRm Rev3 and Stingray cameras
only)
• Flourescent option – B
6. Lumencor SPECTRA 6 Light Engine fiber-coupled illumination unit (can be used with pco.edge 4.2
camera only)
7. Lumencor illumination adapter and cable
April 3, 2014 - Rev 1 3DHISTECH Ltd. 16(127)
