Pannoramic MIDI 1.18 User’s Guide 4 Software Description
Service
Figure 18 – Service panel
This panel contains control and maintenance functions.
Emergency Manual Slide Removal Position
The slide holder will be moved to a position where the slide can be removed manually after
opening the cover (see section 5.3.1 Opening the protective covers).
Slide Removed Manually
Click this button to notify the software that you have removed the slide manually.
4.2.4 Event Call Settings
Figure 19 – Event Call Settings
April 3, 2014 - Rev 1 3DHISTECH Ltd. 40(127)
