Pannoramic MIDI 1.18 User’s Guide 4 Software Description
Two of the three settings are responsible for opening external applications (.exe or .bat) as defined.
For example, Pannoramic Viewer software can be opened after finishing scanning, or the computer
can be turned off after scanning is finished. You can define external application call settings for the
following cases:
• Slide Scanning Finished
• Scanning Error Occurred
For Slide Scanning Finished and Scanning Error Occurred you can define the external software by
entering the file path in the Application box, or by browsing for it by clicking .
If you define parameters in the Parameters box, it will pass them to the software that it starts. If no
parameter is defined, then the parameter will not be passed. The default parameters are the
following:
• For Scan Finished Call: "<SLIDENAME>" – transfers the slide name
• For Error Occurred Call: "<ERRORTEXT>" – transfers the error message
Run defines the window mode that the external application will start in. The following window
modes can be set:
• Normal window
• Minimized
• Maximized
You can test whether the Scanning Error Occurred settings work by clicking . By moving
the mouse cursor over the buttons, the software displays information about the setting you are
interested in.
In the Message Call section of the window complex messaging functions can be defined. Here you
can setup parameters of the mail server, add or remove users, and also set the message body in the
Message subject field by entering a text for example, to inform recipients on the location of the
scanner, or the slide set you are working with.
Click Test to test settings (by sending an e-mail to the address defined in the E-mail To field) after you
have finished to check their relevancy before applying them.
April 3, 2014 - Rev 1 3DHISTECH Ltd. 41(127)
