3D Histech Pannoramic MIDI User Manual

Pannoramic MIDI 1.17 User’s Guide 2 Installation
1. Status display
2. DVD drive (RW)
3. Power on/off button
4. Earphone and microphone 3.5mm Jack ports
5. 2x USB port
6. Power supply connector
7. PS/2 mouse port
8. PS/2 keyboard port
9. 4x USB port
10. 2x USB port
11. Network port
12. Matrox Solios CameraLink ports (for CIS camera)
13. Matrox Solios CameraLink ports (for pco.edge 4.2 camera)
14. 2x FireWire port (IEEE 1394 A/B, for Stingray F146C or AxioCam MRm Rev3 cameras)
2.2 Connectors and cables
Caution!
It is not recommended to use USB and FireWire cables longer than 2.5
meters.
• Control – USB (between scanner and control computer)
• Preview camera – USB cable (between scanner and control computer)
• Stingray – FireWire 1394 B cable (between Stingray camera and control computer)
• AxioCam – FireWire 1394 A cable (between AxioCam camera and control computer)
• CIS – a pair of CameraLink cables (between CIS camera and control computer)
• pco.edge 4.2 – a pair of CameraLink cables (between pco.edge 4.2 camera and control
computer)
• Video cable (between monitor and control computer)
• Power supply cable (between 230V/110V and monitor)
• Power supply cable (between 230V/110V and Lumencor unit)
• Power supply cable (between 230V/110V and control computer)
• Power supply cable (between 230V/110V and power supply unit)
• Power supply cable (between 230V/110V and HXP 120 fluorescent illumination unit)
April 3, 2014 - Rev. 1 3DHISTECH Ltd.
23(127)

3D Histech Pannoramic MIDI Specifications

General

Brand	3D Histech
Model	Pannoramic MIDI
Category	Laboratory Equipment
Language	English
