Pannoramic MIDI 1.18 User’s Guide 4 Software Description
Barcode settings can be modified in the Barcode Settings window. By predefining barcode type,
foreground color ( black or white – the color of the barcode), and other settings, you enable the Read
Barcode option when using the control software.
Note:
You can only scan the barcode type that you have previously set. If you
want to read several barcode types, you always have to set the current
barcode type before reading it.
Functions
• To move a slide to the loading position, click the number of the slide that you want to load
.
• To load a slide from the tray to the specimen holder, click . A preview image is
automatically generated.
• To unload the slide, click .
• To remove the tray, click . It will then be moved to the position where you can
remove it manually.
To display an image of the barcode area, click . You can redefine the barcode reading
area by dragging the edges of the green square.
To check whether the barcode reading settings are correct, display the barcode digits in the Barcode
field by clicking .
Note:
If you did not set the barcode type correctly, or there is no barcode in
the barcode area, the software will display the following error
message: “Barcode detection unsuccessful! There might be no barcode
present.”
1D Barcode Types
You can select the following 1D barcode types:
• Code 128
• Code 93
