Pannoramic MIDI 1.18 User’s Guide 4 Software Description
To insert and remove slides
• To load the tray, click . The system checks the positions for slides during the loading
process.
• If you do not want to load all slides, you can specify the first and last slide to be loaded in
the Scan Range by entering the appropriate slide numbers in the selection boxes of First
slide and Last slide.
• To remove the tray, click . It will then be moved to a position where you can remove
it manually. Slide in the specimen holder is unloaded to the tray before the process.
You also find the button on this panel, that you can start scanning with, but it is
recommended to go through all the settings before clicking it.
Scan Range
You can select a range of slides to be scanned here by entering the first and last slides in the
selection boxes.
To administer profiles, use the Scan Profiles field.
• The current profile name is displayed at the bottom left corner of the screen.
• To save the current profile, click Save.
• To select an existing profile from the selection menu, click Load.
• You can delete the current profile by clicking Delete.
To access the Scan Options window, click .
Note:
These settings are only applicable if you do not use profiles. If you use
profiles, the settings stored in them are used. The used profile name is
indicated at the bottom left of the main window.
For more information, see section 4.5.2 Scan Options.
April 3, 2014 - Rev 1 3DHISTECH Ltd. 90(127)
