3D Histech Pannoramic MIDI User Manual

Pannoramic MIDI 1.18 User’s Guide 4 Software Description
Multilayer Settings
By clicking the the Multilayer Settings window is displayed. The containing
settings are the same as in Brightfield mode, but you can select extended focus or Z-stack
value for the specific channel.
Figure 60 – Filter properties window
Set the focus level value under the Number of focus levels box, and the Focus step size
(one step = 0.2 μm).
Once you have set the correct values, tick the multilayer checkbox (EF or ZS column) of the
channel for which you want to apply these settings, or activate Enable Multilayer function
in the Filter Properties window.
For more information about Extended Focus, see section 4.3.5 Focus panel.
April 3, 2014 - Rev 1 3DHISTECH Ltd. 93(127)

3D Histech Pannoramic MIDI Specifications

General

Brand	3D Histech
Model	Pannoramic MIDI
Category	Laboratory Equipment
Language	English
