A10 Thunder Series - Attach the End Brackets to the Rack

A10 Thunder Series 6430(S) ADC/CGN
Rack-Mount Installation
page 12
4. Repeat for the other side of the chassis.
Attach the End Brackets to the Rack
To attach the end brackets to the rack, use two pan-head screws to attach each end bracket to the
rack.
NOTE: Do not tighten the screws yet. You will need to be able to adjust them
when inserting the chassis.
The example shown here is for a 4-post rack. To install in a 2-post rack, attach the end
brackets to the 2 center posts.
