A10 Thunder Series 6430(S) ADC/CGN
Power Supply Unit Installation
This guide describes how to connect the power supply unit to an applicable AC or DC power source.
The following topics are covered:
• Overview
• DC Power Supply Installation
• Power Supply Hot Swap
CAUTION: Do not attempt to install or operate damaged equipment. As with any
electrical equipment, personal injury or damage to other equipment can
result from commissioning damaged electrical equipment.
NOTE: Follow all applicable regulations for installation of electrical equipment;
for example, in the United States of America, the National Electrical
Code.
For devices with multiple power supplies, it is recommended that all
power supplies be plugged in.
Overview
AC or DC power connections are made using a hot-swap power cable, which enables quick and easy
installation of the power supplies without the need to disturb the AC or DC terminal blocks. AC or DC
power is connected to each module separately.
Before extracting a power supply from the chassis, you must disconnect it from the power source. This
is required regardless of whether the power supply is in standby mode or powered on mode. Likewise,
when installing a power supply, insert the power supply into the chassis first, before connecting the
power supply to the power source.
