A10 Thunder Series 6430(S) ADC/CGN
Rack-Mount Installation
Insert the Chassis Into the Rack
To insert the chassis into the rack:
1. Carefully lift the chassis into place, sliding the inner rail back into each of the 4 end brackets. Make
sure each inner rail is inserted into both of its end rails.
CAUTION: Lifting the Thunder 6430(S) chassis and placing it in the rails is a two-
person job. If needed, use an appropriate lifting device.
2. After the chassis is inserted into all 4 end brackets, tighten the screws that attach the end brackets
to the chassis.
3. Use the #2 Phillips-head screwdriver to tighten each end bracket to the inner rail.
