page 17
A10 Thunder Series 6430(S) ADC/CGN
Getting Started
FIGURE 10 Inner Rail Closeup
NOTE: Shows an inner rail attached to the chassis.
Following are the ear brackets closeup. Either set of ear brackets can be used depending on preference
and rack used. The examples in this guide show the wide ear brackets.
FIGURE 11 Wide
FIGURE 12 Narrow
Required Tools
To install the rail kit, you will need the following tools:
• Anti-static wrist strap and conductive foam pad (recommended).
• #1 Phillips-head screwdriver.
